Retina-Inspired X-Ray Optoelectronic Synapse Using Amorphous Ga2O3 Thin Film.

Abstract

Machine vision techniques are widely applied for object identification in daily life and industrial production, where images are captured and processed by sensors, memories, and processing units sequentially. Neuromorphic optoelectronic synapses, as a preferable option to promote the efficiency of image recognition, are hotly pursued in non-ionizing radiation range, but rarely in ionizing radiation including X-rays. Here, the study proposes an X-ray optoelectronic synapse using amorphous Ga₂O₃ (a-Ga₂O₃) thin film. Boosted by the interfacial V_O ²⁺ defects and its slow neutralization rate, the enhanced electron tunneling process at metal/a-Ga₂O₃ interface produces remarkable X-ray-induced post-synaptic current, contributing to a sensitivity of 20.5, 64.3, 164.1 µC mGy^-1 cm^-2 for the 1st, 5th, and 10th excitation periods, respectively. Further, a 64 × 64 imaging sensor is constructed on a commercial amorphous Si (a-Si) thin film transistor (TFT) array. The image contrast can be apparently improved under a series of X-ray pulses due to an outstanding long-term plasticity of the single pixel, which is beneficial to the subsequent image recognition and classification based on artificial neural network. The merits of large-scale production ability and good compatibility with modern microelectronic techniques belonging to amorphous oxide semiconductors may promote the development of neuro-inspired X-ray imagers and corresponding machine vision systems.
