Technoeconomic Analysis of a Wind Power Generation System and Wind Resource Mapping Using GIS Tools: The Case of Twelve Locations in the Commune of Evodoula, Cameroon

Abstract

This paper performs a technoeconomic analysis of the wind power potential and evaluates the cost of wind power generation in Evodoula, comparing two methods, the conventional method and the uncertainty method based on a comparative spatiotemporal approach using the geographic information system (GIS) software tool. This study is based on satellite wind data measured at 10 m above ground level (AGL) over a 40-year period (1980-2019), by the meteorological service NASA (National Aeronautics and Space Administration)/Goddard Space Flight Center (GSFC). The main objectives are to obtain an appropriate design for a proven optimal location and to assess the viability of wind power at Evodoula. For this type of study, there is little literature available. The optimization of an onshore wind farm and deployment in the wind energy development interest area (ZIDEE) is carried out to obtain a minimum and parsimonious discounted cost production unitary (CPU) of the electricity produced. The results showed that in Okok, a location with a large energy deficit, an onshore wind farm with an electricity generation capacity of 12.5 MW with 5 NORDEX N100-2.5MW wind turbines would have a total energy production (TEP) of about 64.0254825 TWh and a selling price of electricity that would be 0.0034 CAD$/kWh, which is very low compared to the utility price (about 98% cheaper). The total cost of the wind farm would be about $11 million, with a net present cost of about $218 million. The annual profit generated by the wind farm would be over $6 billion. The return on investment (ROI) of the project is estimated at 2880.882%. The constructed onshore wind farm would avoid CO₂ emission at over 11 MtCO₂,_eq/year as the energy generated is from the atmosphere. The wind farm would realize an average annual cash flow estimated at nearly $30 million after 20 years of operation. These savings would allow the installation of CO₂ capture systems in conventional power plants. In addition, the analysis of uncertainties and risks was identified and quantified to estimate the confidence levels of the project development results. The risks have been assessed, and we recommend that the total uncertainty of the project is around 15%. The energy values in P₇₅ and P₉₀ are 10.08% and 19.22%, respectively, lower than the energy value in P₅₀ of 11.60 GWh/An. Finally, the main policy recommendations for an inclusive design process are highlighted. The contribution of this study is to assist policy makers in making appropriate decisions in the development and implementation of energy and environmental policy in Cameroon and in many continental areas.
