Development of a Combined 2D-MGD TLC/HPTLC Method for the Separation of Terpinen-4-ol and α-Terpineol from Tea Tree, Melaleuca alternifolia, Essential Oil.

Abstract

Tea tree oil (TTO), acquired from Melaleuca alternifolia (Maiden & Betche) Cheel, Myrtaceae, is a widely utilized essential oil (EO) due to its bioactive properties. The identification and quantification of TTO ingredients is generally performed by GC-MS, which provides the most accurate results. However, in some instances, the cost and time of analysis may pose a challenge. Thin-layer chromatography (TLC) and high-performance thin-layer chromatography (HPTLC) offer a simpler, faster, cost-effective alternative capable of simultaneously analyzing and quantifying multiple samples. In addition, for more complex oils, two-dimensional (2D) or multigradient development (MGD) TLC provide better separation. Nevertheless, further development is sometimes necessary for the isolation of comigrating components. This study showcases a combined 2D-MGD TLC/HPTLC method for the successful separation of TTO components of interest. While human error, limited separation, and the partial evaporation of volatile components may still present a challenge during the process, considerable recovery of mono- and sesquiterpenes was achieved. This protocol also resulted in the successful isolation of target oxygenated monoterpenes (OMs) producing highly pure terpinen-4-ol (100%) and α-terpineol (≥94%), confirmed by GC-MS. The accurate enantiomeric distribution of these major OMs was verified by GC-FID through the use of a chiral cyclodextrin-based stationary phase. The observed positive enantiomer range (area percent) as well as (+)/(-) ratio for each terpinen-4-ol and α-terpineol were within acceptable ISO criteria.
