Sphenoid Wing Dural Arteriovenous Fistulas.

Abstract

The sphenoid wing dural arteriovenous fistulas (DAVFs) are clinically rare. They often present as non-sinus-type arteriovenous fistulas (AVFs) and may be associated with focal neurological deficits, intracranial venous hypertension, and intracranial hemorrhage. These cases are classified as lesser or greater sphenoid wing lesions. We searched the PubMed databases for studies evaluating the clinical presentation, surgical treatment, and endovascular treatment of these lesions and analyzed 37 cases from 22 papers. A total of 17 cases had lesser sphenoid wing AVFs, and the localization of the shunts could be divided into the sinus of the lesser sphenoid wing (SLSW) or the superficial middle cerebral vein (SMCV). Most SLSW AVFs drained into the cavernous sinus, but two cases drained directly into the deep middle cerebral vein via a bridging vein. All cases with shunts directly into the SMCV had reflux into the SMCV with varices. A total of 20 cases had shunts in the greater sphenoid wing, and the localization of the shunts varied, with shunt localization, and venous return morphology dependent on variations in middle fossa venous return. Most cases had shunts in the sphenobasal vein near the foramen ovale. However, some cases had shunts in the superior ophthalmic vein, sphenopetrosal vein, and laterocavernous sinus. Many were associated with cortical venous reflux. These lesions have been treated by surgical ligation of the drainage vein and transarterial or transvenous embolization. Recently, embolization has become the standard treatment for DAVFs due to advances in endovascular techniques. This paper reviewed and discussed the angioarchitecture, clinical presentation, and treatment of these lesions to clarify the characteristics of sphenoid wing DAVFs.
