可降解、本质阻燃和高性能桐油基环氧树脂的设计

IF 3.9 2区 化学 Q2 POLYMER SCIENCE Polymer Chemistry Pub Date : 2025-01-07 DOI:10.1039/d5py00141b
Qianyong Chang , Kun Zhang , Wenbin Li , Yanqing Wang , Ke Li , Yigang Wang , Xiaoan Nie , Jie Chen
{"title":"可降解、本质阻燃和高性能桐油基环氧树脂的设计","authors":"Qianyong Chang ,&nbsp;Kun Zhang ,&nbsp;Wenbin Li ,&nbsp;Yanqing Wang ,&nbsp;Ke Li ,&nbsp;Yigang Wang ,&nbsp;Xiaoan Nie ,&nbsp;Jie Chen","doi":"10.1039/d5py00141b","DOIUrl":null,"url":null,"abstract":"<div><div>The performance of carbon fiber-reinforced composites (CFRCs) is mainly influenced by the resin matrix. In this study, eleostearic acid was utilized as the raw material, with DOPO serving as the flame-retardant functional group, and dynamic ester bonds were introduced to construct tung oil-based flame-retardant epoxy vitrimers (DGEBA-MSPDGE), which were subsequently applied in the preparation of CFRCs. This approach was aimed to address two major challenges of CFRCs: flammability and recyclability. With DGEBA-MNA cured with commercial methyl nadic anhydride (MNA) as a control, DGEBA-MSPDGE-1 exhibited excellent mechanical properties, and achieved a tensile strength of 81.4 MPa and an elongation at break of 3.83%, which were both superior to those of DGEBA-MNA (76.1 MPa and 2.86%, respectively). DGEBA-MSPDGE attained a limiting oxygen index of 36.4% and a UL-94 V-0 rating in a vertical burning test, and demonstrated blow-off effects during evaluation. The peak heat release rate and total heat release for DGEBA-MSPDGE-1 compared to those of DGEBA-MNA were reduced by 40% and 46%, respectively, which indicate excellent flame retardancy properties. It displayed excellent chemical degradability by completely degrading within five hours under mild conditions. Notably, the recovered carbon fibers (CFs) retained their original chemical structure, mechanical properties, and surface morphology, which facilitated non-destructive recycling of CFs. Therefore, this research provides a viable strategy for fabricating high-performance, fire-safe and recyclable CFRCs.</div></div>","PeriodicalId":100,"journal":{"name":"Polymer Chemistry","volume":"16 16","pages":"Pages 1846-1857"},"PeriodicalIF":3.9000,"publicationDate":"2025-01-07","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":"{\"title\":\"Design of degradable, intrinsically flame-retardant and high-performance tung-oil-based epoxy vitrimers†\",\"authors\":\"Qianyong Chang ,&nbsp;Kun Zhang ,&nbsp;Wenbin Li ,&nbsp;Yanqing Wang ,&nbsp;Ke Li ,&nbsp;Yigang Wang ,&nbsp;Xiaoan Nie ,&nbsp;Jie Chen\",\"doi\":\"10.1039/d5py00141b\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<div><div>The performance of carbon fiber-reinforced composites (CFRCs) is mainly influenced by the resin matrix. In this study, eleostearic acid was utilized as the raw material, with DOPO serving as the flame-retardant functional group, and dynamic ester bonds were introduced to construct tung oil-based flame-retardant epoxy vitrimers (DGEBA-MSPDGE), which were subsequently applied in the preparation of CFRCs. This approach was aimed to address two major challenges of CFRCs: flammability and recyclability. With DGEBA-MNA cured with commercial methyl nadic anhydride (MNA) as a control, DGEBA-MSPDGE-1 exhibited excellent mechanical properties, and achieved a tensile strength of 81.4 MPa and an elongation at break of 3.83%, which were both superior to those of DGEBA-MNA (76.1 MPa and 2.86%, respectively). DGEBA-MSPDGE attained a limiting oxygen index of 36.4% and a UL-94 V-0 rating in a vertical burning test, and demonstrated blow-off effects during evaluation. The peak heat release rate and total heat release for DGEBA-MSPDGE-1 compared to those of DGEBA-MNA were reduced by 40% and 46%, respectively, which indicate excellent flame retardancy properties. It displayed excellent chemical degradability by completely degrading within five hours under mild conditions. Notably, the recovered carbon fibers (CFs) retained their original chemical structure, mechanical properties, and surface morphology, which facilitated non-destructive recycling of CFs. Therefore, this research provides a viable strategy for fabricating high-performance, fire-safe and recyclable CFRCs.</div></div>\",\"PeriodicalId\":100,\"journal\":{\"name\":\"Polymer Chemistry\",\"volume\":\"16 16\",\"pages\":\"Pages 1846-1857\"},\"PeriodicalIF\":3.9000,\"publicationDate\":\"2025-01-07\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Polymer Chemistry\",\"FirstCategoryId\":\"92\",\"ListUrlMain\":\"https://www.sciencedirect.com/org/science/article/pii/S1759995425001081\",\"RegionNum\":2,\"RegionCategory\":\"化学\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q2\",\"JCRName\":\"POLYMER SCIENCE\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Polymer Chemistry","FirstCategoryId":"92","ListUrlMain":"https://www.sciencedirect.com/org/science/article/pii/S1759995425001081","RegionNum":2,"RegionCategory":"化学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q2","JCRName":"POLYMER SCIENCE","Score":null,"Total":0}
引用次数: 0

摘要

碳纤维增强复合材料(CFRCs)的性能主要受树脂基体的影响。本研究以桐油酸为原料,以DOPO为阻燃官能团,引入动态酯键构建桐油基阻燃环氧树脂(DGEBA-MSPDGE),并将其应用于CFRCs的制备。这种方法旨在解决CFRCs的两个主要挑战:可燃性和可回收性。以商品甲基酸酐(MNA)固化的DGEBA-MNA为对照,DGEBA-MSPDGE-1具有优异的力学性能,抗拉强度为81.4 MPa,断裂伸长率为3.83%,均优于DGEBA-MNA (76.1 MPa和2.86%)。在垂直燃烧测试中,DGEBA-MSPDGE达到了36.4%的极限氧指数和UL-94 V-0等级,并在评估中表现出了吹灭效果。与DGEBA-MSPDGE-1相比,DGEBA-MSPDGE-1的峰值放热率和总放热率分别降低了40%和46%,表现出优异的阻燃性能。在温和的条件下,5小时内完全降解,表现出优异的化学降解性。值得注意的是,回收的碳纤维保持了原有的化学结构、机械性能和表面形貌,有利于碳纤维的非破坏性回收。因此,本研究为制备高性能、防火安全、可回收的CFRCs提供了可行的策略。
本文章由计算机程序翻译,如有差异,请以英文原文为准。

摘要图片

摘要图片

查看原文
分享 分享
微信好友 朋友圈 QQ好友 复制链接
本刊更多论文
Design of degradable, intrinsically flame-retardant and high-performance tung-oil-based epoxy vitrimers†
The performance of carbon fiber-reinforced composites (CFRCs) is mainly influenced by the resin matrix. In this study, eleostearic acid was utilized as the raw material, with DOPO serving as the flame-retardant functional group, and dynamic ester bonds were introduced to construct tung oil-based flame-retardant epoxy vitrimers (DGEBA-MSPDGE), which were subsequently applied in the preparation of CFRCs. This approach was aimed to address two major challenges of CFRCs: flammability and recyclability. With DGEBA-MNA cured with commercial methyl nadic anhydride (MNA) as a control, DGEBA-MSPDGE-1 exhibited excellent mechanical properties, and achieved a tensile strength of 81.4 MPa and an elongation at break of 3.83%, which were both superior to those of DGEBA-MNA (76.1 MPa and 2.86%, respectively). DGEBA-MSPDGE attained a limiting oxygen index of 36.4% and a UL-94 V-0 rating in a vertical burning test, and demonstrated blow-off effects during evaluation. The peak heat release rate and total heat release for DGEBA-MSPDGE-1 compared to those of DGEBA-MNA were reduced by 40% and 46%, respectively, which indicate excellent flame retardancy properties. It displayed excellent chemical degradability by completely degrading within five hours under mild conditions. Notably, the recovered carbon fibers (CFs) retained their original chemical structure, mechanical properties, and surface morphology, which facilitated non-destructive recycling of CFs. Therefore, this research provides a viable strategy for fabricating high-performance, fire-safe and recyclable CFRCs.
