Enabling Si‐dominant Anodes: Influence of Neutralization Degree of Polyacrylic Acid on Low‐Cost Micron‐Sized Silicon Anode in High‐Energy Li‐Ion Full Cell

IF 5.1 4区 材料科学 Q2 ELECTROCHEMISTRY Batteries & Supercaps Pub Date : 2024-07-11 DOI:10.1002/batt.202400330
Gabriele Kloker, Dragoljub Vrankovic, Nikhil Arya, Thomas Diemant, Montaha Anjass
{"title":"Enabling Si‐dominant Anodes: Influence of Neutralization Degree of Polyacrylic Acid on Low‐Cost Micron‐Sized Silicon Anode in High‐Energy Li‐Ion Full Cell","authors":"Gabriele Kloker, Dragoljub Vrankovic, Nikhil Arya, Thomas Diemant, Montaha Anjass","doi":"10.1002/batt.202400330","DOIUrl":null,"url":null,"abstract":"Micron‐sized silicon is a promising low‐cost, abundant material to increase the energy density of lithium‐ion batteries. Nevertheless, significant volume change and therefore excessive solid electrolyte interphase (SEI) growth lead to fast capacity fading. In this work, polyacrylic acid (PAA) with different neutralization degrees is used for the fabrication of Si anodes for practical applications. The electrochemical performance in full pouch cells reveals that the increase in neutralization degree of PAA up to 70% enhances the overall performance by improved electrode properties, higher first cycle efficiency (FCE up to 78.1% at C/3) and better capacity retention (85.4% after 150 cycles at 1C) over cycling, while with even higher neutralization degrees (such as 80%) the performance declines. Since proper mixing of the slurry is another important factor, we optimized the mixing procedure by increasing the solid content of the slurry, which has shown positive influence on the electrochemical performance and electrode properties. To summarize, this work shows full cell 1C cycling until capacity retention of 85% after 150 cycles with pure Si microparticle anodes for 70% neutralized PAA as well as increased C‐rate performance up to 5C. Post‐mortem, less degradation on electrode and particle level is observed.","PeriodicalId":132,"journal":{"name":"Batteries & Supercaps","volume":"99 1","pages":""},"PeriodicalIF":5.1000,"publicationDate":"2024-07-11","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":null,"platform":"Semanticscholar","paperid":null,"PeriodicalName":"Batteries & Supercaps","FirstCategoryId":"88","ListUrlMain":"https://doi.org/10.1002/batt.202400330","RegionNum":4,"RegionCategory":"材料科学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q2","JCRName":"ELECTROCHEMISTRY","Score":null,"Total":0}
引用次数: 0

Abstract

Micron‐sized silicon is a promising low‐cost, abundant material to increase the energy density of lithium‐ion batteries. Nevertheless, significant volume change and therefore excessive solid electrolyte interphase (SEI) growth lead to fast capacity fading. In this work, polyacrylic acid (PAA) with different neutralization degrees is used for the fabrication of Si anodes for practical applications. The electrochemical performance in full pouch cells reveals that the increase in neutralization degree of PAA up to 70% enhances the overall performance by improved electrode properties, higher first cycle efficiency (FCE up to 78.1% at C/3) and better capacity retention (85.4% after 150 cycles at 1C) over cycling, while with even higher neutralization degrees (such as 80%) the performance declines. Since proper mixing of the slurry is another important factor, we optimized the mixing procedure by increasing the solid content of the slurry, which has shown positive influence on the electrochemical performance and electrode properties. To summarize, this work shows full cell 1C cycling until capacity retention of 85% after 150 cycles with pure Si microparticle anodes for 70% neutralized PAA as well as increased C‐rate performance up to 5C. Post‐mortem, less degradation on electrode and particle level is observed.
查看原文
分享 分享
微信好友 朋友圈 QQ好友 复制链接
本刊更多论文
实现硅主导阳极:聚丙烯酸中和度对高能量锂离子全电池中低成本微米级硅阳极的影响
微米级硅是一种有望提高锂离子电池能量密度的低成本、丰富的材料。然而,显著的体积变化和过量的固体电解质相(SEI)生长会导致容量快速衰减。在这项研究中,不同中和度的聚丙烯酸(PAA)被用于制造实际应用中的硅阳极。全袋电池的电化学性能表明,将 PAA 的中和度提高到 70% 会改善电极性能、提高首次循环效率(C/3 下的 FCE 高达 78.1%)和更好的容量保持率(1C 下循环 150 次后的 85.4%),从而提高整体性能。由于浆料的适当混合是另一个重要因素,我们通过增加浆料的固体含量来优化混合程序,这对电化学性能和电极特性产生了积极影响。总之,这项研究表明,在 70% 中和 PAA 的情况下,使用纯硅微颗粒阳极进行全电池 1C 循环,直到 150 个循环后容量保持率达到 85%,并且 C 速率性能提高到 5C。事后观察发现,电极和微粒的降解程度较低。
本文章由计算机程序翻译,如有差异,请以英文原文为准。
