Revisiting the Effect of the Resistance to Gas Accumulation in Constant Volume Systems on the Membrane Time Lag.

IF 3.3 4区 工程技术 Q2 CHEMISTRY, PHYSICAL Membranes Pub Date : 2024-07-30 DOI:10.3390/membranes14080167
Peter Jr Leszczynski, Siamak Lashkari, Boguslaw Kruczek
{"title":"Revisiting the Effect of the Resistance to Gas Accumulation in Constant Volume Systems on the Membrane Time Lag.","authors":"Peter Jr Leszczynski, Siamak Lashkari, Boguslaw Kruczek","doi":"10.3390/membranes14080167","DOIUrl":null,"url":null,"abstract":"<p><p>The time-lag method is commonly used to determine membrane permeability, diffusivity and solubility in a single gas permeation experiment in a constant volume system. An unwritten assumption on which this method relies is that there is no resistance to gas accumulation in the downstream receiver of the system. However, this is not the case, even with the specially designed receiver used in this study when, in addition to tubing, the receiver utilizes an additional accumulation tank. The resistance to gas accumulation originates from a finite diffusivity (Knudsen diffusion) of gases in tubing, which are magnified by \"resistance-free\" accumulation tank(s). As a result of the resistance to gas accumulation, the time lag of the membrane is underestimated, which leads to an overestimation of gas diffusivity in the membrane. The experimentally predicted resistances in different configurations of the receiver, expressed by the difference in the time lag at two different receiver locations, were several times greater than the theoretically predicted values. A high molecular PPO membrane was used to demonstrate this effect. The time lags measured at different locations differed by as much as 30%. The diffusivity of nitrogen in a PPO of 4.04 × 10<sup>-12</sup> m<sup>2</sup>/s determined at the optimum configuration of the receiver is at least 50% lower than the literature-reported values.</p>","PeriodicalId":18410,"journal":{"name":"Membranes","volume":null,"pages":null},"PeriodicalIF":3.3000,"publicationDate":"2024-07-30","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC11355954/pdf/","citationCount":"0","resultStr":null,"platform":"Semanticscholar","paperid":null,"PeriodicalName":"Membranes","FirstCategoryId":"5","ListUrlMain":"https://doi.org/10.3390/membranes14080167","RegionNum":4,"RegionCategory":"工程技术","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q2","JCRName":"CHEMISTRY, PHYSICAL","Score":null,"Total":0}
引用次数: 0

Abstract

The time-lag method is commonly used to determine membrane permeability, diffusivity and solubility in a single gas permeation experiment in a constant volume system. An unwritten assumption on which this method relies is that there is no resistance to gas accumulation in the downstream receiver of the system. However, this is not the case, even with the specially designed receiver used in this study when, in addition to tubing, the receiver utilizes an additional accumulation tank. The resistance to gas accumulation originates from a finite diffusivity (Knudsen diffusion) of gases in tubing, which are magnified by "resistance-free" accumulation tank(s). As a result of the resistance to gas accumulation, the time lag of the membrane is underestimated, which leads to an overestimation of gas diffusivity in the membrane. The experimentally predicted resistances in different configurations of the receiver, expressed by the difference in the time lag at two different receiver locations, were several times greater than the theoretically predicted values. A high molecular PPO membrane was used to demonstrate this effect. The time lags measured at different locations differed by as much as 30%. The diffusivity of nitrogen in a PPO of 4.04 × 10-12 m2/s determined at the optimum configuration of the receiver is at least 50% lower than the literature-reported values.

查看原文
分享 分享
微信好友 朋友圈 QQ好友 复制链接
本刊更多论文
重新审视恒容系统中气体积聚阻力对薄膜时滞的影响。
时滞法通常用于在恒定体积系统中的一次气体渗透实验中确定膜渗透性、扩散性和溶解性。这种方法所依赖的一个不成文的假设是,在系统的下游接收器中没有气体积聚的阻力。然而,事实并非如此,即使是本研究中使用的特殊设计的接收器,除管道外,接收器还使用了一个额外的积聚罐。气体积聚的阻力来自管路中气体的有限扩散率(克努森扩散),而 "无阻力 "积聚罐放大了这一阻力。由于气体积聚的阻力,膜的时滞被低估,从而导致膜中气体扩散率被高估。实验预测的不同配置接收器的阻力(以两个不同接收器位置的时滞差表示)比理论预测值大几倍。高分子 PPO 膜被用来证明这种效应。在不同位置测得的时滞相差高达 30%。在接收器的最佳配置下测定的 PPO 中氮的扩散率为 4.04 × 10-12 m2/s,比文献报道的值至少低 50%。
