Inter-reader agreement of the BI-RADS CEM lexicon.

IF 4.7 2区 医学 Q1 RADIOLOGY, NUCLEAR MEDICINE & MEDICAL IMAGING European Radiology Pub Date : 2024-11-06 DOI:10.1007/s00330-024-11176-7
Calogero Zarcaro, Ambra Santonocito, Layla Zeitouni, Francesca Ferrara, Panagiotis Kapetas, Ruxandra-Iulia Milos, Thomas H Helbich, Pascal A T Baltzer, Paola Clauser
{"title":"Inter-reader agreement of the BI-RADS CEM lexicon.","authors":"Calogero Zarcaro, Ambra Santonocito, Layla Zeitouni, Francesca Ferrara, Panagiotis Kapetas, Ruxandra-Iulia Milos, Thomas H Helbich, Pascal A T Baltzer, Paola Clauser","doi":"10.1007/s00330-024-11176-7","DOIUrl":null,"url":null,"abstract":"<p><strong>Purpose: </strong>The purpose of this study was to assess the inter-reader agreement of the breast imaging reporting and data system (BI-RADS) contrast-enhanced mammography (CEM) lexicon.</p><p><strong>Materials and methods: </strong>In this IRB-approved, single-center, retrospective study, three breast radiologists, each with different levels of experience, reviewed 462 lesions in 421 routine clinical CEM according to the fifth edition of the BI-RADS lexicon for mammography and to the first version of the BI-RADS lexicon for CEM. Readers were blinded to patient outcomes and evaluated breast and lesion features on low-energy (LE) images (breast density, type of lesion, associated architectural distortion), lesion features on recombined (RC) images (type of enhancement, characteristic of mass enhancement, non-mass enhancement or enhancing asymmetry), and provided a final BI-RADS assessment. The inter-reader agreement was calculated for each evaluated feature using Fleiss' kappa coefficient. Sensitivity and specificity were calculated.</p><p><strong>Results: </strong>The inter-reader agreement was moderate to substantial for breast density (ĸ = 0.569), type of lesion on LE images (ĸ = 0.654), and type of enhancement (ĸ = 0.664). There was a moderate to substantial agreement on CEM mass enhancement descriptors. The agreement was fair to moderate for non-mass enhancement and enhancing asymmetry descriptors. Inter-reader agreement for LE and LE with RC BI-RADS assessment was moderate (ĸ = 0.421) and fair (ĸ = 0.364). Diagnostic performance was good and comparable for all readers.</p><p><strong>Conclusion: </strong>Inter-reader agreement of the CEM lexicon was moderate to substantial for most features. There was a low agreement for some RC descriptors, such as non-mass enhancement and enhancing asymmetry, and BI-RADS assessment, but this did not impact the diagnostic performance.</p><p><strong>Key points: </strong>Question Data on the reproducibility and inter-reader agreement for the first version of the BI-RADS lexicon dedicated to CEM are missing. Finding The inter-reader agreement for the lexicon was overall substantial to moderate, but it was lower for the descriptors for non-mass enhancement and enhancing asymmetry. Clinical relevance A common lexicon simplifies communication between specialists in clinical practice. The good inter-reader agreement confirms the effectiveness of the CEM-BIRADS in ensuring consistent communication. Detailed definitions of some descriptors (non-mass, enhancing asymmetry) are needed to ensure higher agreements.</p>","PeriodicalId":12076,"journal":{"name":"European Radiology","volume":" ","pages":""},"PeriodicalIF":4.7000,"publicationDate":"2024-11-06","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":null,"platform":"Semanticscholar","paperid":null,"PeriodicalName":"European Radiology","FirstCategoryId":"3","ListUrlMain":"https://doi.org/10.1007/s00330-024-11176-7","RegionNum":2,"RegionCategory":"医学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q1","JCRName":"RADIOLOGY, NUCLEAR MEDICINE & MEDICAL IMAGING","Score":null,"Total":0}
引用次数: 0

Abstract

Purpose: The purpose of this study was to assess the inter-reader agreement of the breast imaging reporting and data system (BI-RADS) contrast-enhanced mammography (CEM) lexicon.

Materials and methods: In this IRB-approved, single-center, retrospective study, three breast radiologists, each with different levels of experience, reviewed 462 lesions in 421 routine clinical CEM according to the fifth edition of the BI-RADS lexicon for mammography and to the first version of the BI-RADS lexicon for CEM. Readers were blinded to patient outcomes and evaluated breast and lesion features on low-energy (LE) images (breast density, type of lesion, associated architectural distortion), lesion features on recombined (RC) images (type of enhancement, characteristic of mass enhancement, non-mass enhancement or enhancing asymmetry), and provided a final BI-RADS assessment. The inter-reader agreement was calculated for each evaluated feature using Fleiss' kappa coefficient. Sensitivity and specificity were calculated.

Results: The inter-reader agreement was moderate to substantial for breast density (ĸ = 0.569), type of lesion on LE images (ĸ = 0.654), and type of enhancement (ĸ = 0.664). There was a moderate to substantial agreement on CEM mass enhancement descriptors. The agreement was fair to moderate for non-mass enhancement and enhancing asymmetry descriptors. Inter-reader agreement for LE and LE with RC BI-RADS assessment was moderate (ĸ = 0.421) and fair (ĸ = 0.364). Diagnostic performance was good and comparable for all readers.

Conclusion: Inter-reader agreement of the CEM lexicon was moderate to substantial for most features. There was a low agreement for some RC descriptors, such as non-mass enhancement and enhancing asymmetry, and BI-RADS assessment, but this did not impact the diagnostic performance.

Key points: Question Data on the reproducibility and inter-reader agreement for the first version of the BI-RADS lexicon dedicated to CEM are missing. Finding The inter-reader agreement for the lexicon was overall substantial to moderate, but it was lower for the descriptors for non-mass enhancement and enhancing asymmetry. Clinical relevance A common lexicon simplifies communication between specialists in clinical practice. The good inter-reader agreement confirms the effectiveness of the CEM-BIRADS in ensuring consistent communication. Detailed definitions of some descriptors (non-mass, enhancing asymmetry) are needed to ensure higher agreements.

查看原文
分享 分享
微信好友 朋友圈 QQ好友 复制链接
本刊更多论文
BI-RADS CEM 词典的读者间一致性。
目的:本研究旨在评估乳腺成像报告和数据系统(BI-RADS)造影剂增强乳腺摄影(CEM)词典的读者间一致性:在这项经 IRB 批准的单中心回顾性研究中,三位乳腺放射科医生根据第五版 BI-RADS 乳腺造影词典和第一版 BI-RADS CEM 词典,分别对 421 例常规临床 CEM 中的 462 个病灶进行了审查,他们的经验水平各不相同。读片者对患者的结果保密,他们评估低能量(LE)图像上的乳腺和病变特征(乳腺密度、病变类型、相关的结构变形)、重组(RC)图像上的病变特征(增强类型、肿块增强特征、非肿块增强或增强不对称),并提供最终的 BI-RADS 评估。使用弗莱斯卡帕系数(Fleiss' kappa coefficient)计算了每个评估特征的读片者间一致性。计算灵敏度和特异性:在乳腺密度(ĸ = 0.569)、LE 图像上的病变类型(ĸ = 0.654)和增强类型(ĸ = 0.664)方面,读片者之间的一致性为中度到高度一致。CEM 质量增强描述符的一致性为中度到高度一致。非质量增强和增强不对称描述符的一致性为一般到中等。LE和LE与RC BI-RADS评估的读片者间一致性为中等(ĸ = 0.421)和一般(ĸ = 0.364)。所有读者的诊断性能良好,具有可比性:结论:就大多数特征而言,CEM 词库的读者间一致性为中等至相当高。结论:对于大多数特征,CEM 词典的读者间一致性为中度至高度一致。对于某些 RC 描述符(如非质量增强和增强不对称)和 BI-RADS 评估,一致性较低,但这并不影响诊断性能:问题: BI-RADS 第一版 CEM 专用词典的可重复性和读者间一致性数据缺失。研究结果 该词典的读者间一致性总体上达到中等水平,但非质量增强和增强不对称的描述符的一致性较低。临床相关性 通用词典简化了临床实践中专家之间的交流。阅读者之间良好的一致性证实了 CEM-BIRADS 在确保一致性交流方面的有效性。需要对某些描述符(非质量、增强不对称)进行详细定义,以确保更高的一致性。
