Improved weighting factor selection method of predictive torque control for PMSM

Abstract

In the traditional predictive torque control strategy, the cost function considers two different control objectives: stator flux and torque. Therefore, it is necessary to reasonably set the weighting factor to ensure that the optimal voltage vector is accurately selected during the control process, thereby achieving better torque and flux control performance. In view of the complex tuning process caused by traditional predictive torque control setting method of weighting factor, a new weighting factor selection method for permanent magnet synchronous motor control system is proposed in this paper. The derivation process is based on the equivalent transformation between the torque–flux prediction and the voltage vector prediction. If both the cost functions of the torque–flux and voltage vector reach their minimum values, the same output voltage vector will be selected. Compared with previous studies, the algorithm proposed in this paper can find the precise location of the optimal weighting factor without changing the form of the cost function, which simplifies the parameter tuning process. Experimental results are also provided to validate the effectiveness of the proposed algorithm.
