Preparation of glass fiber-PVA assisted secondary growth of silver nanowires and flexible conductive films

IF 4.7 3区 材料科学 Q2 MATERIALS SCIENCE, MULTIDISCIPLINARY Materials Chemistry and Physics Pub Date : 2025-03-09 DOI:10.1016/j.matchemphys.2025.130685
Weimin Yan, Chengmin Hou
{"title":"Preparation of glass fiber-PVA assisted secondary growth of silver nanowires and flexible conductive films","authors":"Weimin Yan,&nbsp;Chengmin Hou","doi":"10.1016/j.matchemphys.2025.130685","DOIUrl":null,"url":null,"abstract":"<div><div>Flexible electronics demand conductive films with high stability and conductivity. However, silver nanowires (AgNWs) face challenges like agglomeration and inconsistent morphology. In this study, AgNWs were synthesized via a two-step process: (1) preliminary growth using a glass fiber template and polyol method (diameter: 0.2–0.4 μm, length: 1–6 μm), and (2) secondary growth by mixing AgNWs with PVA solution followed by heat treatment. The secondary growth enhanced nanowire dimensions (diameter: 5–7 μm, length: 100–200 μm) and conductivity. The optimized film exhibited stable resistance (4 MΩ) after 5000 bends (90° and 180°) and achieved optimal performance at 100 °C/30 min. This method provides a scalable solution for flexible electronics.</div></div>","PeriodicalId":18227,"journal":{"name":"Materials Chemistry and Physics","volume":"338 ","pages":"Article 130685"},"PeriodicalIF":4.7000,"publicationDate":"2025-03-09","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":null,"platform":"Semanticscholar","paperid":null,"PeriodicalName":"Materials Chemistry and Physics","FirstCategoryId":"88","ListUrlMain":"https://www.sciencedirect.com/science/article/pii/S0254058425003311","RegionNum":3,"RegionCategory":"材料科学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q2","JCRName":"MATERIALS SCIENCE, MULTIDISCIPLINARY","Score":null,"Total":0}
引用次数: 0

Abstract

Flexible electronics demand conductive films with high stability and conductivity. However, silver nanowires (AgNWs) face challenges like agglomeration and inconsistent morphology. In this study, AgNWs were synthesized via a two-step process: (1) preliminary growth using a glass fiber template and polyol method (diameter: 0.2–0.4 μm, length: 1–6 μm), and (2) secondary growth by mixing AgNWs with PVA solution followed by heat treatment. The secondary growth enhanced nanowire dimensions (diameter: 5–7 μm, length: 100–200 μm) and conductivity. The optimized film exhibited stable resistance (4 MΩ) after 5000 bends (90° and 180°) and achieved optimal performance at 100 °C/30 min. This method provides a scalable solution for flexible electronics.

Abstract Image

查看原文
分享 分享
微信好友 朋友圈 QQ好友 复制链接
本刊更多论文
玻璃纤维-聚乙烯醇辅助银纳米线和柔性导电膜二次生长的制备
柔性电子产品需要具有高稳定性和导电性的导电薄膜。然而,银纳米线(AgNWs)面临着团聚和形态不一致等挑战。在本研究中,AgNWs的合成分为两步:(1)采用玻璃纤维模板和多元醇法(直径:0.2-0.4 μm,长度:1 - 6 μm)进行初步生长,(2)将AgNWs与PVA溶液混合并进行热处理进行二次生长。二次生长增强了纳米线的尺寸(直径5 ~ 7 μm,长度100 ~ 200 μm)和电导率。优化后的薄膜在5000次弯曲(90°和180°)后表现出稳定的电阻(4 MΩ),并在100°C/30分钟下达到最佳性能。该方法为柔性电子产品提供了可扩展的解决方案。
