Improving the Seebeck Coefficient and Electrical Conductivity of Fe₁₁Ti₃Al₆ by Substituting Fe with Cr.

IF 2.2 4区工程技术 Q3 ENGINEERING, ELECTRICAL & ELECTRONIC Journal of Electronic Materials Pub Date : 2025-01-01 Epub Date: 2025-01-10 DOI:10.1007/s11664-024-11723-4

Sukhwinder Singh, Joseph Alemzadeh, Guillermo Menendez Rodriguez, Matthew Phillips, Daniel Zabek, Matthew Burton, Victoria G Rocha, Gao Min

{"title":"Improving the Seebeck Coefficient and Electrical Conductivity of Fe11Ti3Al6 by Substituting Fe with Cr.","authors":"Sukhwinder Singh, Joseph Alemzadeh, Guillermo Menendez Rodriguez, Matthew Phillips, Daniel Zabek, Matthew Burton, Victoria G Rocha, Gao Min","doi":"10.1007/s11664-024-11723-4","DOIUrl":null,"url":null,"abstract":"In general, any attempt to increase the Seebeck coefficient is usually accompanied by a decrease in the electrical conductivity or vice versa due to the interplay between these two parameters. This work demonstrates that a simultaneous increase in both the Seebeck coefficient and electrical conductivity can be obtained by \"doping\" in intermetallic alloys. A new alloy composition, Fe10Cr1Ti3Al6, was synthesized by substituting Fe with Cr in Fe11Ti3Al6 using mechanical alloying and spark plasma sintering (SPS). The thermoelectric measurements revealed that the Cr substitution led to an increase in the Seebeck coefficient from +27 µV/K in Fe11Ti3Al6 to +39 µV/K in Fe10Cr1Ti3Al6, with a corresponding increase in the electrical conductivity from 2.5 × 105 S/m to 4.7 × 105 S/m, resulting in a significant increase in the power factor. The temperature dependence of the thermoelectric properties of this new alloy was also investigated over a temperature range of 50-727°C. The result showed that a maximum power factor of 6.0 × 10-4 W/m K2 was obtained at 53°C.","PeriodicalId":626,"journal":{"name":"Journal of Electronic Materials","volume":"54 4","pages":"2701-2709"},"PeriodicalIF":2.2000,"publicationDate":"2025-01-01","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC11903524/pdf/","citationCount":"0","resultStr":null,"platform":"Semanticscholar","paperid":null,"PeriodicalName":"Journal of Electronic Materials","FirstCategoryId":"5","ListUrlMain":"https://doi.org/10.1007/s11664-024-11723-4","RegionNum":4,"RegionCategory":"工程技术","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"2025/1/10 0:00:00","PubModel":"Epub","JCR":"Q3","JCRName":"ENGINEERING, ELECTRICAL & ELECTRONIC","Score":null,"Total":0}

引用次数: 0

Abstract

In general, any attempt to increase the Seebeck coefficient is usually accompanied by a decrease in the electrical conductivity or vice versa due to the interplay between these two parameters. This work demonstrates that a simultaneous increase in both the Seebeck coefficient and electrical conductivity can be obtained by "doping" in intermetallic alloys. A new alloy composition, Fe₁₀Cr₁Ti₃Al₆, was synthesized by substituting Fe with Cr in Fe₁₁Ti₃Al₆ using mechanical alloying and spark plasma sintering (SPS). The thermoelectric measurements revealed that the Cr substitution led to an increase in the Seebeck coefficient from +27 µV/K in Fe₁₁Ti₃Al₆ to +39 µV/K in Fe₁₀Cr₁Ti₃Al₆, with a corresponding increase in the electrical conductivity from 2.5 × 10⁵ S/m to 4.7 × 10⁵ S/m, resulting in a significant increase in the power factor. The temperature dependence of the thermoelectric properties of this new alloy was also investigated over a temperature range of 50-727°C. The result showed that a maximum power factor of 6.0 × 10^-4 W/m K² was obtained at 53°C.

查看原文
