Yue Yan, Xunzhou Xiao, Qinxue Nie, Zhen Wang, Yifan Chen, Jiahao Wu, Nansen Zhou, Renjie Zhou, Sen Yang, Wei Ren
{"title":"光纤尖腔中的纳升级光-物质相互作用实现了灵敏的光热气体检测","authors":"Yue Yan, Xunzhou Xiao, Qinxue Nie, Zhen Wang, Yifan Chen, Jiahao Wu, Nansen Zhou, Renjie Zhou, Sen Yang, Wei Ren","doi":"10.1002/lpor.202400907","DOIUrl":null,"url":null,"abstract":"Laser spectroscopy offers a significant tool for revealing specific molecular details with the desired accuracy and sensitivity. However, it poses challenges to maintain high sensitivity when targeting a micro‐region. Here, a dual‐enhanced photothermal approach is presented using a high‐finesse fiber Fabry–Pérot (F–P) cavity, tailored for highly sensitive chemical sensing with nanoliter‐scale light–matter interaction. A spheric surface (diameter: 50 µm, radius of curvature: 910 µm) is created on the fiber tip using focused ion beam milling. By adding a high‐reflectivity dielectric coating to the spheric surface, a fiber F–P cavity is obtained with a length of 473 µm and a finesse exceeding 4000. The intra‐cavity pump light within the gas‐filled fiber cavity generates a strong photothermal effect upon gas absorption. This effect induces phase modulation, which is amplified and detected by coupling a probe laser to the fiber cavity‐based interferometer. A minimum detection limit of 10 parts‐per‐billion (ppb) of C<jats:sub>2</jats:sub>H<jats:sub>2</jats:sub> at 1530.37 nm is demonstrated using only 1 mW of pump power, corresponding to a normalized noise equivalent absorption coefficient of 9.1×10<jats:sup>−11</jats:sup> cm<jats:sup>−1</jats:sup>∙W∙Hz<jats:sup>−1/2</jats:sup>. This platform breaks the bottleneck of ultrasensitive gas detection with a very short light–matter interaction length, promising significant advancements in microscale chemical analysis through optical investigations.","PeriodicalId":204,"journal":{"name":"Laser & Photonics Reviews","volume":null,"pages":null},"PeriodicalIF":9.8000,"publicationDate":"2024-08-23","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":"{\"title\":\"Nanoliter‐Scale Light–Matter Interaction in a Fiber‐Tip Cavity Enables Sensitive Photothermal Gas Detection\",\"authors\":\"Yue Yan, Xunzhou Xiao, Qinxue Nie, Zhen Wang, Yifan Chen, Jiahao Wu, Nansen Zhou, Renjie Zhou, Sen Yang, Wei Ren\",\"doi\":\"10.1002/lpor.202400907\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"Laser spectroscopy offers a significant tool for revealing specific molecular details with the desired accuracy and sensitivity. However, it poses challenges to maintain high sensitivity when targeting a micro‐region. Here, a dual‐enhanced photothermal approach is presented using a high‐finesse fiber Fabry–Pérot (F–P) cavity, tailored for highly sensitive chemical sensing with nanoliter‐scale light–matter interaction. A spheric surface (diameter: 50 µm, radius of curvature: 910 µm) is created on the fiber tip using focused ion beam milling. By adding a high‐reflectivity dielectric coating to the spheric surface, a fiber F–P cavity is obtained with a length of 473 µm and a finesse exceeding 4000. The intra‐cavity pump light within the gas‐filled fiber cavity generates a strong photothermal effect upon gas absorption. This effect induces phase modulation, which is amplified and detected by coupling a probe laser to the fiber cavity‐based interferometer. A minimum detection limit of 10 parts‐per‐billion (ppb) of C<jats:sub>2</jats:sub>H<jats:sub>2</jats:sub> at 1530.37 nm is demonstrated using only 1 mW of pump power, corresponding to a normalized noise equivalent absorption coefficient of 9.1×10<jats:sup>−11</jats:sup> cm<jats:sup>−1</jats:sup>∙W∙Hz<jats:sup>−1/2</jats:sup>. This platform breaks the bottleneck of ultrasensitive gas detection with a very short light–matter interaction length, promising significant advancements in microscale chemical analysis through optical investigations.\",\"PeriodicalId\":204,\"journal\":{\"name\":\"Laser & Photonics Reviews\",\"volume\":null,\"pages\":null},\"PeriodicalIF\":9.8000,\"publicationDate\":\"2024-08-23\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Laser & Photonics Reviews\",\"FirstCategoryId\":\"101\",\"ListUrlMain\":\"https://doi.org/10.1002/lpor.202400907\",\"RegionNum\":1,\"RegionCategory\":\"物理与天体物理\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q1\",\"JCRName\":\"OPTICS\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Laser & Photonics Reviews","FirstCategoryId":"101","ListUrlMain":"https://doi.org/10.1002/lpor.202400907","RegionNum":1,"RegionCategory":"物理与天体物理","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q1","JCRName":"OPTICS","Score":null,"Total":0}
Nanoliter‐Scale Light–Matter Interaction in a Fiber‐Tip Cavity Enables Sensitive Photothermal Gas Detection
Laser spectroscopy offers a significant tool for revealing specific molecular details with the desired accuracy and sensitivity. However, it poses challenges to maintain high sensitivity when targeting a micro‐region. Here, a dual‐enhanced photothermal approach is presented using a high‐finesse fiber Fabry–Pérot (F–P) cavity, tailored for highly sensitive chemical sensing with nanoliter‐scale light–matter interaction. A spheric surface (diameter: 50 µm, radius of curvature: 910 µm) is created on the fiber tip using focused ion beam milling. By adding a high‐reflectivity dielectric coating to the spheric surface, a fiber F–P cavity is obtained with a length of 473 µm and a finesse exceeding 4000. The intra‐cavity pump light within the gas‐filled fiber cavity generates a strong photothermal effect upon gas absorption. This effect induces phase modulation, which is amplified and detected by coupling a probe laser to the fiber cavity‐based interferometer. A minimum detection limit of 10 parts‐per‐billion (ppb) of C2H2 at 1530.37 nm is demonstrated using only 1 mW of pump power, corresponding to a normalized noise equivalent absorption coefficient of 9.1×10−11 cm−1∙W∙Hz−1/2. This platform breaks the bottleneck of ultrasensitive gas detection with a very short light–matter interaction length, promising significant advancements in microscale chemical analysis through optical investigations.
