界面热耗散在有机场效应晶体管运行稳定性中的关键作用。

IF 11.7 1区 综合性期刊 Q1 MULTIDISCIPLINARY SCIENCES Science Advances Pub Date : 2024-09-06 DOI:10.1126/sciadv.adn5964
Kai Tie, Jiannan Qi, Yongxu Hu, Yao Fu, Shougang Sun, Yanpeng Wang, Yinan Huang, Zhongwu Wang, Liqian Yuan, Liqiang Li, Dacheng Wei, Xiaosong Chen, Wenping Hu
{"title":"界面热耗散在有机场效应晶体管运行稳定性中的关键作用。","authors":"Kai Tie,&nbsp;Jiannan Qi,&nbsp;Yongxu Hu,&nbsp;Yao Fu,&nbsp;Shougang Sun,&nbsp;Yanpeng Wang,&nbsp;Yinan Huang,&nbsp;Zhongwu Wang,&nbsp;Liqian Yuan,&nbsp;Liqiang Li,&nbsp;Dacheng Wei,&nbsp;Xiaosong Chen,&nbsp;Wenping Hu","doi":"10.1126/sciadv.adn5964","DOIUrl":null,"url":null,"abstract":"<div >The operational stability becomes a key issue affecting the commercialization for organic field-effect transistors (OFETs). It is widely recognized to be closely related to the defects and traps at the interface between dielectric and organic semiconductors, but this understanding does not always effectively address operational instability, implying that the factors influencing the operational stability have not been fully understood. Here, we reveal that the self-heating effect is another crucial factor in operational stability. By using hexagonal boron nitride (hBN) to assist interfacial thermal dissipation, the dinaphtho[2,3-b:2′,3′-f]thieno[3,2-b]thiophene (DNTT) FETs exhibit high mobility of 14.18 cm<sup>2</sup> V<sup>−1</sup> s<sup>−1</sup> and saturated power density up to 1.8 × 10<sup>4</sup> W cm<sup>−2</sup>. The OFET can operate at a power density of 1.06 × 10<sup>4</sup> W cm<sup>−2</sup> for 30,000 s with negligible performance degradation, showing excellent operational stability under high power density. This work deepens the understanding on operational stability and develops an effective way for ultrahigh stable devices.</div>","PeriodicalId":21609,"journal":{"name":"Science Advances","volume":null,"pages":null},"PeriodicalIF":11.7000,"publicationDate":"2024-09-06","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"https://www.science.org/doi/reader/10.1126/sciadv.adn5964","citationCount":"0","resultStr":"{\"title\":\"Crucial role of interfacial thermal dissipation in the operational stability of organic field-effect transistors\",\"authors\":\"Kai Tie,&nbsp;Jiannan Qi,&nbsp;Yongxu Hu,&nbsp;Yao Fu,&nbsp;Shougang Sun,&nbsp;Yanpeng Wang,&nbsp;Yinan Huang,&nbsp;Zhongwu Wang,&nbsp;Liqian Yuan,&nbsp;Liqiang Li,&nbsp;Dacheng Wei,&nbsp;Xiaosong Chen,&nbsp;Wenping Hu\",\"doi\":\"10.1126/sciadv.adn5964\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<div >The operational stability becomes a key issue affecting the commercialization for organic field-effect transistors (OFETs). It is widely recognized to be closely related to the defects and traps at the interface between dielectric and organic semiconductors, but this understanding does not always effectively address operational instability, implying that the factors influencing the operational stability have not been fully understood. Here, we reveal that the self-heating effect is another crucial factor in operational stability. By using hexagonal boron nitride (hBN) to assist interfacial thermal dissipation, the dinaphtho[2,3-b:2′,3′-f]thieno[3,2-b]thiophene (DNTT) FETs exhibit high mobility of 14.18 cm<sup>2</sup> V<sup>−1</sup> s<sup>−1</sup> and saturated power density up to 1.8 × 10<sup>4</sup> W cm<sup>−2</sup>. The OFET can operate at a power density of 1.06 × 10<sup>4</sup> W cm<sup>−2</sup> for 30,000 s with negligible performance degradation, showing excellent operational stability under high power density. This work deepens the understanding on operational stability and develops an effective way for ultrahigh stable devices.</div>\",\"PeriodicalId\":21609,\"journal\":{\"name\":\"Science Advances\",\"volume\":null,\"pages\":null},\"PeriodicalIF\":11.7000,\"publicationDate\":\"2024-09-06\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"https://www.science.org/doi/reader/10.1126/sciadv.adn5964\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Science Advances\",\"FirstCategoryId\":\"103\",\"ListUrlMain\":\"https://www.science.org/doi/10.1126/sciadv.adn5964\",\"RegionNum\":1,\"RegionCategory\":\"综合性期刊\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q1\",\"JCRName\":\"MULTIDISCIPLINARY SCIENCES\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Science Advances","FirstCategoryId":"103","ListUrlMain":"https://www.science.org/doi/10.1126/sciadv.adn5964","RegionNum":1,"RegionCategory":"综合性期刊","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q1","JCRName":"MULTIDISCIPLINARY SCIENCES","Score":null,"Total":0}
引用次数: 0

摘要

工作稳定性是影响有机场效应晶体管(OFET)商业化的一个关键问题。人们普遍认为这与介电质和有机半导体界面上的缺陷和陷阱密切相关,但这种认识并不总能有效地解决工作不稳定性问题,这意味着影响工作稳定性的因素尚未被完全理解。在这里,我们揭示了自热效应是影响运行稳定性的另一个关键因素。通过使用六方氮化硼(hBN)来帮助界面散热,二萘并[2,3-b:2',3'-f]噻吩并[3,2-b]噻吩(DNTT)场效应晶体管表现出 14.18 cm2 V-1 s-1 的高迁移率和高达 1.8 × 104 W cm-2 的饱和功率密度。该场效应晶体管可在 1.06 × 104 W cm-2 的功率密度下工作 30,000 秒,性能下降几乎可以忽略不计,显示出在高功率密度下出色的工作稳定性。这项工作加深了人们对工作稳定性的理解,并为超高稳定器件开发了一条有效途径。
本文章由计算机程序翻译,如有差异,请以英文原文为准。
查看原文
分享 分享
微信好友 朋友圈 QQ好友 复制链接
本刊更多论文
Crucial role of interfacial thermal dissipation in the operational stability of organic field-effect transistors
The operational stability becomes a key issue affecting the commercialization for organic field-effect transistors (OFETs). It is widely recognized to be closely related to the defects and traps at the interface between dielectric and organic semiconductors, but this understanding does not always effectively address operational instability, implying that the factors influencing the operational stability have not been fully understood. Here, we reveal that the self-heating effect is another crucial factor in operational stability. By using hexagonal boron nitride (hBN) to assist interfacial thermal dissipation, the dinaphtho[2,3-b:2′,3′-f]thieno[3,2-b]thiophene (DNTT) FETs exhibit high mobility of 14.18 cm2 V−1 s−1 and saturated power density up to 1.8 × 104 W cm−2. The OFET can operate at a power density of 1.06 × 104 W cm−2 for 30,000 s with negligible performance degradation, showing excellent operational stability under high power density. This work deepens the understanding on operational stability and develops an effective way for ultrahigh stable devices.
