Efficient and Ultrastable Seawater Electrolysis at Industrial Current Density with Strong Metal-Support Interaction and Dual Cl−-Repelling Layers

IF 27.4 1区 材料科学 Q1 CHEMISTRY, MULTIDISCIPLINARY Advanced Materials Pub Date : 2024-10-25 DOI:10.1002/adma.202408982
Dong Liu, Xiaotian Wei, Jianxi Lu, Xin Wang, Kai Liu, Yaohai Cai, Yingwei Qi, Lei Wang, Haoqiang Ai, Zhenbo Wang
{"title":"Efficient and Ultrastable Seawater Electrolysis at Industrial Current Density with Strong Metal-Support Interaction and Dual Cl−-Repelling Layers","authors":"Dong Liu, Xiaotian Wei, Jianxi Lu, Xin Wang, Kai Liu, Yaohai Cai, Yingwei Qi, Lei Wang, Haoqiang Ai, Zhenbo Wang","doi":"10.1002/adma.202408982","DOIUrl":null,"url":null,"abstract":"Direct seawater electrolysis is emerging as a promising renewable energy technology for large-scale hydrogen generation. The development of Os-Ni<sub>4</sub>Mo/MoO<sub>2</sub> micropillar arrays with strong metal-support interaction (MSI) as a bifunctional electrocatalyst for seawater electrolysis is reported. The micropillar structure enhances electron and mass transfer, extending catalytic reaction steps and improving seawater electrolysis efficiency. Theoretical and experimental studies demonstrate that the strong MSI between Os and Ni<sub>4</sub>Mo/MoO<sub>2</sub> optimizes the surface electronic structure of the catalyst, reducing the reaction barrier and thereby improving catalytic activity. Importantly, for the first time, a dual Cl<sup>−</sup> repelling layer is constructed by electrostatic force to safeguard active sites against Cl<sup>−</sup> attack during seawater oxidation. This includes a strong Os─Cl adsorption and an in situ-formed MoO<sub>4</sub><sup>2−</sup> layer. As a result, the Os-Ni<sub>4</sub>Mo/MoO<sub>2</sub> catalyst exhibits an ultralow overpotential of 113 and 336 mV to reach 500 mA cm<sup>−2</sup> for HER and OER in natural seawater from the South China Sea (without purification, with 1 <span>m</span> KOH added). Notably, it demonstrates superior stability, degrading only 0.37 µV h<sup>−1</sup> after 2500 h of seawater oxidation, significantly surpassing the technical target of 1.0 µV h<sup>−1</sup> set by the United States Department of Energy.","PeriodicalId":114,"journal":{"name":"Advanced Materials","volume":null,"pages":null},"PeriodicalIF":27.4000,"publicationDate":"2024-10-25","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":null,"platform":"Semanticscholar","paperid":null,"PeriodicalName":"Advanced Materials","FirstCategoryId":"88","ListUrlMain":"https://doi.org/10.1002/adma.202408982","RegionNum":1,"RegionCategory":"材料科学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q1","JCRName":"CHEMISTRY, MULTIDISCIPLINARY","Score":null,"Total":0}
引用次数: 0

Abstract

Direct seawater electrolysis is emerging as a promising renewable energy technology for large-scale hydrogen generation. The development of Os-Ni4Mo/MoO2 micropillar arrays with strong metal-support interaction (MSI) as a bifunctional electrocatalyst for seawater electrolysis is reported. The micropillar structure enhances electron and mass transfer, extending catalytic reaction steps and improving seawater electrolysis efficiency. Theoretical and experimental studies demonstrate that the strong MSI between Os and Ni4Mo/MoO2 optimizes the surface electronic structure of the catalyst, reducing the reaction barrier and thereby improving catalytic activity. Importantly, for the first time, a dual Cl repelling layer is constructed by electrostatic force to safeguard active sites against Cl attack during seawater oxidation. This includes a strong Os─Cl adsorption and an in situ-formed MoO42− layer. As a result, the Os-Ni4Mo/MoO2 catalyst exhibits an ultralow overpotential of 113 and 336 mV to reach 500 mA cm−2 for HER and OER in natural seawater from the South China Sea (without purification, with 1 m KOH added). Notably, it demonstrates superior stability, degrading only 0.37 µV h−1 after 2500 h of seawater oxidation, significantly surpassing the technical target of 1.0 µV h−1 set by the United States Department of Energy.

Abstract Image

查看原文
分享 分享
微信好友 朋友圈 QQ好友 复制链接
本刊更多论文
工业电流密度下的高效超稳定海水电解,具有强金属支撑相互作用和双拒氯层
海水直接电解正在成为大规模制氢的一种前景广阔的可再生能源技术。本研究开发了具有强金属-支撑相互作用(MSI)的 Os-Ni4Mo/MoO2 微柱阵列,作为海水电解的双功能电催化剂。微柱结构增强了电子和质量传递,延长了催化反应步骤,提高了海水电解效率。理论和实验研究表明,Os 和 Ni4Mo/MoO2 之间的强 MSI 优化了催化剂的表面电子结构,降低了反应势垒,从而提高了催化活性。重要的是,在海水氧化过程中,该催化剂首次通过静电力构建了双Cl-排斥层,以保护活性位点免受Cl-的侵蚀。这包括一个强 Os─Cl 吸附层和一个原位形成的 MoO42- 层。因此,Os-Ni4Mo/MoO2 催化剂的过电位极低,分别为 113 mV 和 336 mV,在中国南海的天然海水中(未经净化,添加 1 m KOH),HER 和 OER 的过电位可达 500 mA cm-2。值得注意的是,它还表现出超强的稳定性,在海水氧化 2500 小时后仅衰减 0.37 µV h-1,大大超过了美国能源部设定的 1.0 µV h-1 的技术指标。
本文章由计算机程序翻译,如有差异,请以英文原文为准。
