Comparison of noninvasive electrical cardiometry and transpulmonary thermodilution for cardiac output measurement in critically ill patients: a prospective observational study.
Wenliang Song, Jiayan Guo, Daiyin Cao, Jinlong Jiang, Tao Yang, Xiaoxun Ma, Hao Yuan, Jianfeng Wu, Xiangdong Guan, Xiang Si
{"title":"Comparison of noninvasive electrical cardiometry and transpulmonary thermodilution for cardiac output measurement in critically ill patients: a prospective observational study.","authors":"Wenliang Song, Jiayan Guo, Daiyin Cao, Jinlong Jiang, Tao Yang, Xiaoxun Ma, Hao Yuan, Jianfeng Wu, Xiangdong Guan, Xiang Si","doi":"10.1186/s12871-025-03005-1","DOIUrl":null,"url":null,"abstract":"<p><strong>Background: </strong>Cardiac output (CO) monitoring is essential for diagnosing and managing critically ill patients. Recently, a non-invasive haemodynamic monitoring technique, electrical cardiometry (EC), has gathered increasing interest among ICU physicians. This study aimed to explore the accuracy of CO estimated by non-invasive EC (CO<sub>EC</sub>) compared to CO determined by transpulmonary thermodilution (CO<sub>TPTD</sub>) and to evaluate the ability of CO<sub>EC</sub> to track CO<sub>TPTD</sub> changes (ΔCO<sub>TPTD</sub>).</p><p><strong>Methods: </strong>This prospective, observational, single-center study was conducted from April 2021 to April 2023, involving patients who required haemodynamic monitoring using a transpulmonary thermodilution device (PiCCO). CO<sub>TPTD</sub> and CO<sub>EC</sub> were recorded simultaneously, with the investigators obtaining the CO<sub>EC</sub> measurements were blinded to the CO<sub>TPTD</sub> results and vice versa. Agreement between the methods was evaluated using Bland-Altman analysis and percentage error (PE). The ability of CO<sub>EC</sub> to track changes in CO<sub>TPTD</sub> was examined using four-quadrant and polar plots.</p><p><strong>Results: </strong>Seventy-two patients with PiCCO haemodynamic monitoring were included, yielding 285 paired CO measurements. The bias between CO<sub>EC</sub> and CO<sub>TPTD</sub> was 0.47 L/min, with a limit of agreement (LoA) ranging from -2.91 to 3.85 L/min and a PE of 54.0%. Among 212 pairs of ΔCO data, excluding a central zone of 15% in the four-quadrant plot, the concordance rate between ΔCO<sub>EC</sub> % and ΔCO<sub>TPTD</sub> % was 70%. In the polar plot, excluding a central zone with a radius of 0.625 L/min (10% of the mean CO<sub>TPTD</sub>), the mean polar angle for ΔCO<sub>EC</sub> was 2.2°, with a radial LoA of 56.0°. Exploratory subgroup analysis indicated a PE of 47.0% between CO<sub>EC</sub> and CO<sub>TPTD</sub> and a concordance rate of 72% between ΔCO<sub>EC</sub>% and ΔCO<sub>TPTD</sub>% in patients with normal CO (CO ≥ 4 L/min). In patients with elevated thoracic fluid content (TFC > 35 kΩ), the PE between CO<sub>EC</sub> and CO<sub>TPTD</sub> was 45.0%, with a concordance rate of 64% between ΔCO<sub>EC</sub>% and ΔCO<sub>TPTD</sub>%. Additionally, in patients receiving low-dose norepinephrine equivalents (NEE ≤ 0.25 μg/kg/min), CO<sub>EC</sub> and CO<sub>TPTD</sub> exhibited a PE of 45.0%, while ΔCO<sub>EC</sub>% and ΔCO<sub>TPTD</sub>% achieved a concordance rate of 75% and a radial LoA of 44.2°.</p><p><strong>Conclusion: </strong>In critically ill patients, non-invasive EC indicated limited accuracy in measuring CO, along with a restricted ability to reliably track CO changes. These findings suggested that EC may not be interchangeable with TPTD in the general ICU population.</p>","PeriodicalId":9190,"journal":{"name":"BMC Anesthesiology","volume":"25 1","pages":"123"},"PeriodicalIF":2.3000,"publicationDate":"2025-03-13","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":null,"platform":"Semanticscholar","paperid":null,"PeriodicalName":"BMC Anesthesiology","FirstCategoryId":"3","ListUrlMain":"https://doi.org/10.1186/s12871-025-03005-1","RegionNum":3,"RegionCategory":"医学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q2","JCRName":"ANESTHESIOLOGY","Score":null,"Total":0}
引用次数: 0
Abstract
Background: Cardiac output (CO) monitoring is essential for diagnosing and managing critically ill patients. Recently, a non-invasive haemodynamic monitoring technique, electrical cardiometry (EC), has gathered increasing interest among ICU physicians. This study aimed to explore the accuracy of CO estimated by non-invasive EC (COEC) compared to CO determined by transpulmonary thermodilution (COTPTD) and to evaluate the ability of COEC to track COTPTD changes (ΔCOTPTD).
Methods: This prospective, observational, single-center study was conducted from April 2021 to April 2023, involving patients who required haemodynamic monitoring using a transpulmonary thermodilution device (PiCCO). COTPTD and COEC were recorded simultaneously, with the investigators obtaining the COEC measurements were blinded to the COTPTD results and vice versa. Agreement between the methods was evaluated using Bland-Altman analysis and percentage error (PE). The ability of COEC to track changes in COTPTD was examined using four-quadrant and polar plots.
Results: Seventy-two patients with PiCCO haemodynamic monitoring were included, yielding 285 paired CO measurements. The bias between COEC and COTPTD was 0.47 L/min, with a limit of agreement (LoA) ranging from -2.91 to 3.85 L/min and a PE of 54.0%. Among 212 pairs of ΔCO data, excluding a central zone of 15% in the four-quadrant plot, the concordance rate between ΔCOEC % and ΔCOTPTD % was 70%. In the polar plot, excluding a central zone with a radius of 0.625 L/min (10% of the mean COTPTD), the mean polar angle for ΔCOEC was 2.2°, with a radial LoA of 56.0°. Exploratory subgroup analysis indicated a PE of 47.0% between COEC and COTPTD and a concordance rate of 72% between ΔCOEC% and ΔCOTPTD% in patients with normal CO (CO ≥ 4 L/min). In patients with elevated thoracic fluid content (TFC > 35 kΩ), the PE between COEC and COTPTD was 45.0%, with a concordance rate of 64% between ΔCOEC% and ΔCOTPTD%. Additionally, in patients receiving low-dose norepinephrine equivalents (NEE ≤ 0.25 μg/kg/min), COEC and COTPTD exhibited a PE of 45.0%, while ΔCOEC% and ΔCOTPTD% achieved a concordance rate of 75% and a radial LoA of 44.2°.
Conclusion: In critically ill patients, non-invasive EC indicated limited accuracy in measuring CO, along with a restricted ability to reliably track CO changes. These findings suggested that EC may not be interchangeable with TPTD in the general ICU population.
