A Flat Reconstruction of the Medial Collateral Ligament and Anteromedial Structures Restores Native Knee Kinematics: A Biomechanical Robotic Investigation.

Abstract

Background: Injuries of the superficial medial collateral ligament (sMCL) and anteromedial structures of the knee result in excess valgus rotation and external tibial rotation (ER) as well as tibial translation.

Purpose: To evaluate a flat reconstruction of the sMCL and anteromedial structures in restoring knee kinematics in the combined MCL- and anteromedial-deficient knee.

Study design: Controlled laboratory study.

Methods: Eight cadaveric knee specimens were tested in a 6 degrees of freedom robotic test setup. Force-controlled clinical laxity tests were performed with 200 N of axial compression in 0°, 30°, 60°, and 90° of flexion: 8 N·m valgus torque, 5 N·m ER torque, 89 N anterior tibial translation (ATT) force, and an anteromedial drawer test consisting of 89 N ATT force under 5 N·m ER torque. After determining the native knee kinematics, we transected the sMCL, followed by the deep medial collateral ligament (dMCL). Subsequently, a flat reconstruction of the sMCL with anteromedial limb, mimicking the function of the anteromedial corner, was performed. Mixed linear models were used for statistical analysis (P < .05).

Results: Cutting of the sMCL led to statistically significant increases in laxity regarding valgus rotation, ER, and anteromedial translation in all tested flexion angles (P < .05). ATT was significantly increased in all flexion angles but not at 60° after cutting of the sMCL. A combined instability of the sMCL and dMCL led to further increased knee laxity in all tested kinematics and flexion angles (P < .05). After reconstruction, the knee kinematics were not significantly different from those of the native state.

Conclusion: Insufficiency of the sMCL and dMCL led to excess valgus rotation, ER, ATT, and anteromedial tibial translation. A combined flat reconstruction of the sMCL and the anteromedial aspect restored this excess laxity to values not significantly different from those of the native knee.

Clinical relevance: The presented reconstruction might lead to favorable results for patients with MCL and anteromedial injuries with an anteromedial rotatory knee instability.
