Deep learning-based CT-free attenuation correction for cardiac SPECT: a new approach.

Abstract

Background: Computed tomography attenuation correction (CTAC) is commonly used in cardiac SPECT imaging to reduce soft-tissue attenuation artifacts. However, CTAC is prone to inaccuracies due to CT artifacts and SPECT-CT mismatch, along with additional radiation exposure to patients. Thus, these limitations have led to increasing interest in CT-free AC, with deep learning (DL) offering promising solutions. We proposed a new DL-based CT-free AC methods for cardiac SPECT.

Methods: We developed a feature alignment attenuation correction network (FA-ACNet) based on the 3D U-Net framework to generate predicted DL-based AC SPECT (Deep AC). The network was trained on 167 cardiac SPECT/CT studies using 5-fold cross validation and tested in an independent testing set (n = 35), with CTAC serving as the reference. During training, multi-scale features from non-attenuation-corrected (NAC) SPECT and CT were processed separately and then aligned with the encoded features from NAC SPECT using adversarial learning and distance metric learning techniques. The performance of FA-ACNet was evaluated using mean square error (MSE), structural similarity index (SSIM) and peak signal-to-noise ratio (PSNR). Additionally, semi-quantitative evaluation of Deep AC images was performed and compared to CTAC using Bland-Altman plots.

Results: FA-ACNet achieved an MSE of 16.94 ± 2.03 × 10^- 6, SSIM of 0.9955 ± 0.0006 and PSNR of 43.73 ± 0.50 after 5-fold cross validation. Compared to U-Net, MSE and PSNR improved by aligning multi-scale features from NAC SPECT and CT with those from NAC SPECT. In the testing set, FA-ACNet achieved an MSE of 11.98 × 10^- 6, SSIM of 0.9976 and PSNR of 45.54. The 95% limits of agreement (LoAs) between the Deep AC and CTAC images for the summed stress/rest scores (SSS/SRS) were [- 2.3, 2.8] and [-1.9,2.1] in the training set and testing set respectively. Changes in perfusion categories were observed in 4.19% and 5.9% of studies assessed for global perfusion scores in the training set and testing set.

Conclusion: We propose a novel DL-based CT-free AC approach for cardiac SPECT, which can generate AC images without the need for a CT scan. By leveraging multi-scale features from both NAC SPECT and CT, the performance of CT-free AC is significantly enhanced, offering a promising alternative for future DL-based AC strategies.
